ZP/8/16/24 Rotary Tablet Press
Item No.: LPMIE108
ZP Series Advanced Mini Rotary Tablet Press with PLC Touch Screen Control System is designed to press both round and irregular shapes of tablets from various kinds of granular materials.
Description
ZP Series Advanced Mini Rotary Tablet Press with PLC Touch Screen Control System is designed to press both round and irregular shapes of tablets from various kinds of granular materials. It is an excellent press for laboratory or small-scale batch production, which is an upscale from using other counter top rotary presses in the marketplace. The turret carries 8/16/24 sets of punches and dies, so 8/16/24 tablets will be pressed for each revolution of the turret. During operation, the speed of the turret rotation, the depth of the filling material and the thickness of the tablets can be adjusted. The mechanical buffer unit will prevent punches and apparatus from overload damage.
It is a rugged design with high quality stainless steel construction to meet the cGMP Standard; and fully enclosed for a cleaner operating environment. Custom engraving of letters or logos are available upon request. The maximum diameter of tablet is 22mm for round or other irregular shapes of tablets.
Main Features:
- New User's Friendly HMI & Color Touch Screen Control Operations.
- Pre-Compression System.
- Main Compression System.
- Ejection Force Monitoring System.
- Automatically Stops when overload occurred for protecting the punches and dies.
Technical Parameter:
Model | ZP24 | ZP16 | ZP8 | |
Number of Station | Unit | 24 | 16 | 8 |
Tool Type | IPT19 (EU19) BB | IPT1' (EU1') D | IPT1' (EU1') D | |
Max. Diameter of Tablet | mm | 13 | 16 | 22 |
Max. Thickness of Tablet | mm | 6 | 7 | 7 |
Max. Depth of Fill | mm | 15 | 18 | 18 |
Max. Capacity | tablet/h | 21,600-51,840 | 14,400-28,800 | 7,200-14,400 |
Rotary Speed | rpm | 15 - 30 | ||
Upper Punch Entry | mm | 2-8 | 2-8 | 2-8 |
Max. Pre-compression | kN | 10 | ||
Max. Main Compression | kN | 60 | ||
Power of Main Motor | kW | 2.2 | ||
Dimension | mm | 747 x 800 x 1628 | ||
Weight | kg | 550 |
